Belgian Railways Class 28 (Bombardier)

The NMBS/SNCB Class 28 number series has been brought back into use for 43 Bombardier TRAXX locomotives which have been hired from Angel Trains Cargo for use with B-Cargo, the freight division of NMBS/SNCB, since renamed Lineas.[1] They are numbered in two series - they carry their original numbers, E186 123 to E186 125, and E186 196 to E186 220, and have also been numbered into the SNCB number series, 2801 to 2843.[1]

NMBS/SNCB Class 28
Bombardier TRAXX locomotive E186 124 exhibited during the NMBS/SNCB open days at Antwerpen-Noord workshops. This locomotive is now renumbered to 2802.
Type and origin Power type DC Electric Builder Bombardier Transportation Model TRAXX F140 MS2 Build date 2007-2009 Total produced 43
Specifications Configuration: ​  • UIC Bo'Bo' Gauge 1,435 mm (4 ft 8 ^1⁄2 in) Bogies Bo-Bo Length 18,900 mm (62 ft 0 in) Width 2,978 mm (9 ft 9.2 in) Axle load 21.25 ton Loco weight 85 ton Electric system/s 1500 V DC 3000 V DC 25 kV 50 Hz AC 15 kV 16⅔ Hz AC Current pickup(s) Pantograph
Performance figures Maximum speed 160 km/h (99 mph) Power output 5600 kW Tractive effort 300 kN Factor of adh. 2.8 (35.7%)
Career Operators B-Cargo Class 28 Number in class 43 Numbers 2801-2843 Delivered 2007-2009 Current owner Alpha Trains Disposition In service

It was planned that they would work passenger services between Amsterdam, Brecht, Brussels and Antwerp.[1] Several are now running on push-pull Benelux trains, alongside NS Class 186 (NS TRAXX F140 MS). These trains have a locomotive at each end ; some trains feature a Class 186 at one end and a Class 28 at the other one.

They also work on the heavy freight corridor between Aachen-West, Antwerp, and Zeebrugge.

The original SNCB Class 28 locomotives were produced by Baume-Marpent in 1949.

Class 29

5 TRAXX F140 MS locomotives especially prepared for operations into France were numbered 2901 to 2905.

• 2901 ex E 186 346-3
• 2902 ex E 186 347-1 (now with Fret SNCF)[2]
• 2903 ex E 186 348-9
• 2904 ex E 186 349-7
• 2905 ex E 186 350-5

2861 & 2862

During 2015 two additional TRAXX F140 MS locomotives were hired by SNCB and numbered as 2861 & 2862.

• 2861 ex E 186 183-0[3]
• 2862 ex E 186 181-4[4]

They have been joined by E 186 424,[5] covering for locomotives away for maintenance.

•
  2833 on an empty automobile train.
•
  A pair of Class 28 hauling a Benelux train in the Netherlands.
